What specifications do outdoor LED advertising screens generally use
Desciption:
The specifications of the outdoor LED advertising screen can be varied, depending on a variety of factors, including the installation location, viewing distance, budget and the required display effect. Here are some common specifications and features:
Pixel Pitch: Pixel pitch is a key factor in determining #LED screen resolution and display clarity. The pixel pitch commonly used in outdoor LED advertising screens includes P3, P4, P5, P6, P8, P10, etc., where P indicates that the unit of pixel pitch is millimeter. Smaller pixel pitch (such as P3 or P4) provides higher resolution and sharper images for close viewing; Larger pixel pitches, such as P10 to P20, are suitable for long distance viewing at relatively low cost.
Size: The size of the outdoor LED screen can be customized according to actual needs, ranging from a few square meters to dozens or even hundreds of square meters. Larger screens can attract viewers from a longer distance, while smaller screens are suitable for specific viewing areas or specific advertising content.
Brightness: Outdoor LED screens need to have a high brightness, usually between 5000-7500 Nit, and may even reach 10,000 NIT, in order to be clearly visible in daylight. The higher the brightness, the better the screen performs in various lighting conditions.
Protection level: Due to the complexity of the outdoor environment, LED screens need to have a good protection level, usually IP65 to IP68, to withstand adverse weather conditions such as rain, dust and humidity.
Energy consumption: Outdoor LED screens should have energy-saving features to reduce operating costs. Some manufacturers provide energy-saving LED display products, through automatic brightness adjustment and other methods to achieve energy saving and emission reduction.
Installation structure: The installation structure of the outdoor LED screen needs to consider the main factors such as wind resistance, earthquake resistance, load bearing, and coordinate with the surrounding environment.
Viewing Angle: The outdoor LED screen should have a wide viewing Angle, so that the audience in different positions can get a good visual experience.
Customization: Many manufacturers offer customized services that can provide LED screens with different box sizes, shapes and functions according to the unique needs and budgets of customers.
Maintenance: Choose an outdoor LED screen that is easy to maintain, which can reduce the cost and workload of later maintenance.
Content playback: Outdoor LED advertising screen is usually equipped with an advanced playback system, supporting a variety of formats of content playback, including advertising, information release, real-time broadcast and so on.
The selection of specifications for outdoor LED advertising screens should be based on actual application scenarios and needs, as well as the budget and expected effects.
.
Specification:
| Classification |
Item |
Unit |
Parameter |
| Vehicle |
Cabinet Weight |
|
36 KG/Cabinet |
| Type |
|
led |
| Brand Name |
|
Smart led |
| Specification |
|
Video Wall |
| Material |
|
Iron cabinet |
| Media Available |
|
datasheet, Photo, EDA/CAD Models, Other |
| Chassis |
IP Grade |
|
Front side IP65,Back side IP54 |
| Cabinet Resolution |
|
192x192 pixels |
| Cabinet Size(WXHXD) |
|
960mmLx960mmHx145mmD |
| Used |
|
Outdoor |
| Power Consumption |
|
5V 42W |
| HUB Connection |
|
48W |
| Module scan |
|
1/8 scan |
| Engine |
Engine model |
|
CY4100Q |
| Manufacturer |
|
Dongfeng Chaoyang Diesel Engine Co.,Ltd. |
| Fuel type |
|
Diesel |
| Number of axles |
|
2 |
| Engine horse power |
hp |
95 |
| Allowable passengers in cab |
|
2,3 |
| Emission standard |
|
Euro III |
| Driver’s cab |
Brand |
|
dongfeng |
| Model |
|
Flat head, single row |
| Pixel Pitch |
|
8mm |
| Steering |
|
Left hand drive |
| Transmission |
|
5-speed with over drive |
| Operation control system |
|
Electrically hydraulic control |
| Air-conditioning |
|
Optional |
| Standard equipment |
(1) Equipped with three sides (left,right and rear) LED screen.
(2) Three sides are full color P6 screen.
(3) Equipped with left side LED screen hydraulic lifting.
(4) Equipped with 18KW silent diesel generator.
(5) Industrial control computer 1set, amplifiers 1set, waterproof column loudspeaker 4set.
(6) Internal and external power distribution box.
(7) Circulating ventilation cooling system.
(8) Van body roof with exhaust skylight and light.
(9) The truck body material is composite steel frame.
(10) Interior floor is aluminum checkered plate.
|
| No.of tire |
6+1pcs |
| Color &Painting |
According to customer’s requirements |
Application: Widely used for outdoor commercial advertising, stage shows, live broadcast, sports stadium advertising, etc.
Our Services
1. Factory Supply:
a. one of the biggest and professional special using truck manufacturers in china,
b. more than 300 kinds of special truck for your needing.
2. OEM Ability: produce according to your demand, material, size, color and logo are optional for you.
3. Good Quality:
a. has solid technology, advanced equipments; reliant quality, flexible modes of operation and strict quality control system,
b. passed the ISO9001-2008 and the 3C (China Compulsory Certification),
c. our brand is china famous brand with good reputation in the market.
4. Good Service: you can contact us by 24-hour hotline or whatsapp or email.
5. Fast Delivery: 15-20 working days after payment, safe and quick delivery.
FAQ
1. Price term: FOB Shanghai, China or CIF or DAF, according to customers' requirements.
2. Payment: 30-50% deposit after order confirmation, balance should be paid before delivery. All by T/T.
3. Delivery time: 15-20 working days after full payment is received.
4. Standard Steering: Left-hand drive, if you need Right-hand drive, please inform us, will make special order for you.
We highly recommend this mobile LED truck. It's in excellent condition with good quality and competitive price. For further information, please feel free to contact me, we will offer our best service.
