8 - 10 Ton Car Wrecker Tow Truck Platform 6.3T Wheel Base 4500mm Heavy Duty Towing
Desciption:
The 8-10 Ton Car Wrecker Tow Truck is a heavy-duty vehicle designed for towing and recovering vehicles. Below are the key features and specifications of such a tow truck, especially one with a 6.3T platform and a 4500mm wheelbase:
Key Specifications:
Capacity:
Towing Capacity: 8 to 10 tons, suitable for towing a wide range of vehicles, including cars, vans, and light trucks.
Platform Capacity: 6.3 tons, indicating the maximum weight the platform can support.
Chassis:
Wheelbase: 4500mm, providing a stable and robust base for heavy-duty towing operations.
Design: Typically built on a strong and durable chassis to withstand the stresses of towing heavy vehicles.
Engine:
Performance: Equipped with a powerful engine to provide the necessary torque and power for towing heavy loads.
Emission Standards: Designed to meet relevant emission standards, ensuring compliance with environmental regulations.
Towing and Recovery Equipment:
Winch: A powerful winch with adequate pulling capacity to recover disabled vehicles.
Boom: An extendable boom for reaching and lifting vehicles that are difficult to access.
Wheel Lift: A hydraulic wheel lift system for lifting vehicles by the wheels, ensuring safe and secure towing.
Flatbed Platform: A tilting or sliding flatbed platform for loading and transporting vehicles.
Control System:
Hydraulic Controls: Advanced hydraulic systems for smooth and precise operation of the towing equipment.
In-Cab Controls: Operator can control the towing mechanisms from within the cab, enhancing safety and convenience.
Safety Features:
Stabilizers/Outriggers: For additional stability during towing and recovery operations.
Safety Chains and Straps: Essential for securing the towed vehicle.
Lighting and Reflectors: Adequate lighting and reflective markings for visibility and safety, especially during nighttime or low-visibility operations.
Additional Features:
Tool Storage: Compartments for storing tools and additional equipment required for towing and recovery tasks.
Comfort Features: Ergonomic seating, air conditioning, and modern controls in the driver's cab for operator comfort during long hours of operation.
Communication Systems: Often equipped with radio or communication systems for coordination with dispatch and other team members.
Applications:
Vehicle Recovery: Ideal for recovering and towing broken-down or accident-damaged vehicles.
Roadside Assistance: Suitable for towing vehicles as part of roadside assistance services.
Transporting Vehicles: Used for transporting vehicles to repair shops, impound lots, or other destinations.
Would you like more detailed information on any specific aspect of this tow truck?
Specification:
| Classification |
Item |
Unit |
Parameter |
| Vehicle |
Vehicle model |
|
Dongfeng flatbed wrecker with crane |
| Manufacture Year |
|
2020 |
| Overall dimensions |
mm |
9440×2480×3700 |
| Tablet Size |
6200×2480 |
| GVW |
kg |
12495 |
| Curb weight |
10000 |
| Traction system |
|
4×2 |
| Transmission |
|
8-speed with over drive |
| Max speed |
km/h |
98 |
| Chassis |
Chassis model |
|
DFL1120B21 |
| Number of springs |
|
8/10+8 |
| Wheel base |
mm |
4500 |
| Tire specification |
|
10.00R20 |
| Number of tires |
|
6+1 spare |
| F/R track base |
mm |
1880/1860 |
| Engine |
Engine model |
|
B190 33 |
| Manufacturer |
|
DongFeng Cummins Engine CO.,LTD |
| Engine horsepower |
hp |
190 |
| Displacement |
ml |
5900 |
| Emission standard |
|
Euro III |
| Lift function (Crane brand: 5T CLW Balong full rotary crane) |
| Crane weight |
5000kg |
Turning angel |
360° |
| Wire lift quality |
5000 kg |
Corbel telescopic stroke |
1200 mm |
| Max effective length |
1300 mm |
Max tractor speed |
40 km/h |
| Tablet Agency |
| Tablet Size (LxW) |
6200×2480 mm |
Min inclination angle |
10° |
| working stroke |
2700 mm |
Max load mass |
6000 kg |
| Winch parameters |
| Number |
1 |
Rated traction mass |
6000 kg |
| Rope length |
25 m |
Strand speed |
8m / min |
| Production cycle |
20 working days after deposit |
|
|
Application:
Our Services
1. Factory Supply:
a. one of the biggest and professional special using truck manufacturers in china,
b. more than 300 kinds of special truck for your needing.
2. OEM Ability: produce according to your demand, material, size, color and logo are optional for you.
3. Good Quality:
a. has solid technology, advanced equipments; reliant quality, flexible modes of operation and strict quality control system,
b. passed the ISO9001-2008 and the 3C (China Compulsory Certification),
c. our brand is china famous brand with good reputation in the market.
4. Good Service: you can contact us by 24-hour hotline or whatsapp or email.
5. Fast Delivery: 15-20 working days after payment, safe and quick delivery.
FAQ
1. Price term: FOB Shanghai, China or CIF or DAF, according to customers' requirements.
2. Payment: 30-50% deposit after order confirmation, balance should be paid before delivery. All by T/T.
3. Delivery time: 15-20 working days after full payment is received.
4. Standard Steering: Left-hand drive, if you need Right-hand drive, please inform us, will make special order for you.
We highly recommend this wrecker truck with crane. It's in excellent condition with good quality and competitive price. For further information, please feel free to contact me, we will offer our best service.
