Product Description:
Classification of mixing trucks
According to the concrete water content loaded by the concrete mixing truck, there are three kinds of mixing trucks: wet material type, dry material type and semi-dry material type.
Most of the domestic use of wet concrete mixer truck, it can be loaded by the mixing plant (station) production of concrete or according to the proportion of mixed aggregates (sand, stone), cement and water, in the transport process, the wet material slowly mixing, to prevent the concrete in the transport process of initial coagulation and segregation.
However, the time from production to pouring of concrete generally cannot exceed 1.5 hours to avoid concrete condensation.
Therefore, in the case of longer distance transportation, it is necessary to use dry and semi-dry material mixing trucks to transport.
The dry material mixing transport vehicle can directly load the dry aggregate and cement into the mixing cylinder of the vehicle according to the ratio, and the dry material in the cylinder will be stirred during transportation. When the vehicle is about to arrive at the construction site or add water to the construction site to complete the mixing of concrete.
The aggregate and cement in the concrete transported by the semi-dry material mixing truck are also formulated according to the ratio, and contain a certain amount of water, but the content of water does not meet the pouring requirements, and it is necessary to add water to the construction site or the construction site
Features:
- Product Name: Concrete Mixer Truck
- Vehicle dimension: 8550X2496X3850mm
- Mixing capacity(m³): 10
- Displacement: 9726ml
- Loading Capacity: 10 M3
- Wheel base: 3825+1350 Mm
- Concrete mixer truck for sale
- Concrete mixer lorry
- Mixer truck concrete
- Large concrete truck
Technical Parameters:
| Product Attribute |
Specification |
| Product Name |
Concrete Mixer Truck |
| Steering device |
Power Assisted Steering |
| Cab |
HW76 Cab |
| Number of Passengers |
Allowable 3 |
| Air Conditioner |
Yes |
| Curb Weight |
13870kg |
| Vehicle Dimension |
8550X2496X3850mm |
| Loading Capacity |
10 M3 |
| Emission Standard |
Euro 3 |
| Wheel Base |
3825+1350 Mm |
| Water Tank Capacity |
300L |
| Chassis Brand |
SINOTRUK HOWO |
| Steering Wheel |
Left or Right Hand Drive |
Product Description:
The Concrete Mixer Truck, also known as truck mixer truck or concrete lorries, is a specialized vehicle used for transporting and mixing concrete cement. It is commonly used in construction sites and for delivering concrete to remote locations. The truck is equipped with a power assisted steering device for easy maneuvering and has a spacious HW76 cab that can accommodate up to 3 passengers. It also has an air conditioner for comfortable driving in any weather conditions. With a curb weight of 13870kg and dimensions of 8550X2496X3850mm, this truck has a loading capacity of 10 M3 and meets Euro 3 emission standards. It has a wheel base of 3825+1350 Mm and a water tank capacity of 300L. The chassis is made by SINOTRUK HOWO and the steering wheel can be positioned on the left or right hand side depending on the driver's preference. This Concrete Mixer Truck is a reliable and efficient choice for any construction project requiring the transportation and mixing of concrete.
Our Services
1. Factory Supply:
a. one of the biggest and professional special using truck manufacturers in china,
b. more than 300 kinds of special truck for your needing.
2. OEM Ability: produce according to your demand, material, size, color and logo are optional for you.
3. Good Quality:
a. has solid technology, advanced equipments; reliant quality, flexible modes of operation and strict quality control system,
b. passed the ISO9001-2008 and the 3C (China Compulsory Certification),
c. our brand is china famous brand with good reputation in the market.
4. Good Service: you can contact us by 24-hour hotline or whatsapp or email.
5. Fast Delivery: 15-20 working days after payment, safe and quick delivery.
FAQ
1. Price term: FOB Shanghai, China or CIF or DAF, according to customers' requirements.
2. Payment: 30-50% deposit after order confirmation, balance should be paid before delivery. All by T/T.
3. Delivery time: 15-20 working days after full payment is received.
4. Standard Steering: Left-hand drive, if you need Right-hand drive, please inform us, will make special order for you.
We highly recommend this LED billboard truck. It's in excellent condition with good quality and competitive price. For further information, please feel free to contact me, we will offer our best service.
